Phadia™ 250 | Allergy Testing Instrument

Phadia 250 Laboratory System

Fully automated, immunoassay system, aiding in the diagnosis of autoimmune and allergic diseases.

Ideal for labs performing 400-2,000 tests/per week

Size: With table cart: 73 x 50 x 30 in

Maximum throughput: Up to 60 results/hour

Reliability: 98% uptime

Sample type: Serum, plasma

Sample tubes for sample rack: 10 and 16 position rack options, Height: 50-110mm, Diameter: 10-17mm

Testing capabilities: ImmunoCAP^™ Allergy solutions & EliA^™ Autoimmunity solutions

Testing methodology: fluoroenzyme immunoassay (FEIA)

See all details

Ready to gain effortless workflow efficiency with Phadia^™ 250 instrument?

Discover how

Pop the hood and get a good look at the instrument’s capabilities.

3D Tour

Let the Phadia 250 system be the backbone in maximizing your lab’s workflow.

Set up and walkway

With a 15-minute, low hands-on start-up time and automatic shutdown and rinse capability, gain extended periods of walkaway time.¹

28-day stored calibration curve

Using a master calibration curve by isotypes, Phadia 250 system requires less upkeep and generates less waste.¹

Easily scalable systems

The Phadia™ Prime software’s intuitive and user-friendly interface to allow for seamless system management as well as the ability to scale and network multiple Phadia systems from one computer.¹

Don’t stay shackled to the hood.

Gain the freedom to walk away and let the Phadia 250 system do the heavy lifting.
Enhance your lab today.

What is your job role?

What is your speciality?

First Name

Last Name

Organization

State

Zip Code

Country/Region

Message

I confirm that I would like to receive marketing and promotional emails about products and services from Thermo Fisher Scientific Inc. and its affiliates. You may unsubscribe at any time by clicking on the unsubscribe link in any of the marketing communication you receive. By submitting this form you agree to Thermo Fisher Scientific Inc. Terms of Use and Privacy Notice, including transfer of your personal data to countries outside your country of residence.

Chat with us

Save on reagents and time

Phadia 250 system test menu

One lab system with the capabilities of running both ImmunoCAP Allergy solutions and EliA Autoimmunity solutions.

ImmunoCAP Allergy Solutions
EliA Autoimmunity Solutions

Over 550 whole allergens and mixes as well as 100 allergen components that aide in the diagnosis of a wide range of allergies, such as...

Peanut and tree nuts
Milk and egg
Alpha-Gal syndrome

Pollen
Pet dander
And more…

View ImmunoCAP tests

Phadia 250 system's full test menu

More than 30 of the most common autoimmune disease markers for diseases like…

Connective Tissue Disease
Rheumatoid Arthritis
Celiac Disease
Antiphospholipid Syndrome (APS)

Vasculitis/Goodpasture Syndrome
Liver Diseases
Thyroid Diseases

View EliA tests

Phadia 250 system's full test menu

Compare Phadia Laboratory Systems

See how the Phadia 250 system compares to other instruments in our portfolio.

Support doesn’t end after the instrument is installed.

Helping you minimize downtime and strengthen your output through our exceptional customer service, education, and resources.

Phadia™ LabCommunity

Remote troubleshooting and unmatched customer support to ensure maximized uptime.

Phadia™ Prime Software

Intuitive and user-friendly interface to allow for seamless system management as well as the ability to scale and network multiple Phadia systems from one computer.

Phadia Lab Resources

On-site or online training/education, service level agreements, and help establishing instrument benchmarks, reinforcing the support you need, when you need it.

Overhaul your autoimmunity and allergy diagnostics with effortless efficiency.

Incorporate Phadia 250 System

References

Phadia® 250 User Manual 12-3904-01/EN Edition 2.2. published 2017 Sep.
Phadia® 1000 User Manual 12-3803-01/EN Edition 2.6. published 2020 July
Phadia® 2500 and Phadia 5000® User Manual EN Edition 1.1. published 2012 March

	Phadia 200	Phadia 250	Phadia 1000	Phadia 2500+ series	Phadia 5000+ series
ImmunoCAP	Allergy	Allergy	Allergy	Allergy	Allergy
EliA	Autoimmunity	Autoimmunity	N/A	Autoimmunity	Autoimmunity
System Description	Fully-automated closed immunoassay system	Fully-automated closed immunoassay system	Fully-automated closed immunoassay system	Fully-automated closed immunoassay system	Fully-automated closed immunoassay system
Processing	Batch	Continuous	Continuous	Continuous	Continuous
Maximum Throughput	Up to 96 test results per batch	Up to 60 results/hour	Up to 240 results/hour	Up to 480 results/hour	Up to 960 results/hour
Sample Types	Serum, Plasma	Serum, plasma	Serum, plasma	Serum, plasma	Serum, plasma
Sample Tubes for Sample Rack w/ 10 positions	Height 42-100mm Diam. 10-16mm	Height 50-110mm Diam. 10-17mm	Height 50-105mm Diam. 10-17mm	N/A	N/A
Sample Tubes for Sample Rack w/ 5 positions	N/A	N/A	N/A	Height 70-105mm Diam. 10-17mm	Height 70-105mm Diam. 10-17mm
Sample Barcode Types	Code 39, Code 93, Code 128, Codabar (NW-7), COOP 2 of 5, EAN-8, Industrial 2 of 5, Interleave 2–5 *Not for Phadia 200 and Phadia 1000 Use. Phadia 200 not Validated with EAN-8 either	Code 39, Code 93, Code 128, Codabar (NW-7), COOP 2 of 5, EAN-8, Industrial 2 of 5, Interleave 2–5 *Not for Phadia 200 and Phadia 1000 Use. Phadia 200 not Validated with EAN-8 either	Code 39, Code 93, Code 128, Codabar (NW-7), COOP 2 of 5, EAN-8, Industrial 2 of 5, Interleave 2–5 *Not for Phadia 200 and Phadia 1000 Use. Phadia 200 not Validated with EAN-8 either	Code 39, Code 93, Code 128, Codabar (NW-7), COOP 2 of 5, EAN-8, Industrial 2 of 5, Interleave 2–5 *Not for Phadia 200 and Phadia 1000 Use. Phadia 200 not Validated with EAN-8 either	Code 39, Code 93, Code 128, Codabar (NW-7), COOP 2 of 5, EAN-8, Industrial 2 of 5, Interleave 2–5 *Not for Phadia 200 and Phadia 1000 Use. Phadia 200 not Validated with EAN-8 either
Sample Dilution	Allergy Autoimmunity	Allergy Autoimmunity	N/A	Autoimmunity	Autoimmunity
Level and Clot Detection	Yes	Yes	Yes	Yes	Yes
Reflex Testing	Yes	Yes	Yes	Yes	Yes
STAT Samples	No	Yes	No	Yes	Yes
Reagents	General ImmunoCAP and EliA reagents available on board. Loaded batch wise with ImmunoCAP or EliA reagents	General ImmunoCAP and EliA reagents available on board are shared	General ImmunoCAP and EliA reagents available on board are shared	General ImmunoCAP and EliA reagents available on board are shared	General ImmunoCAP and EliA reagents available on board are shared
Type of calibration	One Isotype master curve per assay group (IgG, IgE, IgM, IgA)	One Isotype master curve per assay group (IgG, IgE, IgM, IgA)	One Isotype master curve per assay group (IgG, IgE, IgM, IgA)	One Isotype master curve per assay group (IgG, IgE, IgM, IgA)	One Isotype master curve per assay group (IgG, IgE, IgM, IgA)
Calibration stability	28 days	28 days	28 days	28 days	28 days
Water Requirements for Rinse Solution	Clinical laboratory reagent water (CLRW, may be used in place of Type I and Type II water)*	Clinical laboratory reagent water (CLRW, may be used in place of Type I and Type II water)*	Clinical laboratory reagent water (CLRW, may be used in place of Type I and Type II water)*	Clinical laboratory reagent water (CLRW, may be used in place of Type I and Type II water)*	Clinical laboratory reagent water (CLRW, may be used in place of Type I and Type II water)*
Remote Troubleshooting and Support	Phadia LabCommunity	Phadia LabCommunity	Phadia LabCommunity	Phadia LabCommunity	Phadia LabCommunity
Ambient Operating Temperature	18–32 °C	18–32 °C	18–32 °C	ImmunoCap 18–32 °C EliA 18-29 °C	ImmunoCap 18–32 °C EliA 18-29 °C
Electrical Requirements	110-240V 50/60Hz	100 V, 120 V, 220 V, 230 V, 240 V ±10% 50/60 Hz	200 V, 220 V, 230 V, 240 V±10% 50/60 Hz	200 V, 208 V, 230 V, 240 V±10% 50/60 Hz	200 V, 208 V, 230 V, 240 V±10% 50/60 Hz
Dimensions (HxWxD)	55 x 80 x 60 cm (22 x 32 x 24 in)	186x127x75 cm w/ table 73x50x30 in	215x183x105 cm 85x72x42 in	195x411x135 cm 77x162x53 in	195x619x135 cm 77x244x53 in
Weight (empty)	47 kg/ 104 lb.	220 kg / 485 lb	688 kg / 1516 lb	2000 kg / 4409 lb	3342 kg / 7367 lb
